HOM240CP Square D Homeline Circuit Breaker

HOM240CP Square D Homeline Circuit Breaker

Homeline circuit breaker. Used for overload and short-circuit protection of electrical systems. Compatible with Homeline load centers and CSED devices. Rated for 120 volt/240 volt and 10,000 AIR. Designed exclusively for the residential market. ANSI (American National Standards Institute) certified and UL (Underwriter’s Laboratories) listed. No. HOM115CP: Amperage: 15, Number of Poles: 1, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 1-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM120CP: Amperage: 20, Number of Poles: 1, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 1-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM130CP: Amperage: 30, Number of Poles: 1, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 1-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM115C: Amperage: 15, Number of Poles: 1, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 1-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1, Package Type: Clamshell No. HOM120C: Amperage: 20, Number of Poles: 1, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 1-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1, Package Type: Clamshell No. HOM130C: Amperage: 30, Number of Poles: 1, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 1-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1, Package Type: Clamshell No. HOM215CP: Amperage: 15, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM220CP: Amperage: 20, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM230CP: Amperage: 30, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM240CP: Amperage: 40, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 8-2 AWG, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM250CP: Amperage: 50, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 8-2 AWG, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM260CP: Amperage: 60, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 8-2 AWG, Certification: ANSI/UL Listed, Pkg Qty: 1 No. HOM270CP: Amperage: 70, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 8-2 AWG, Certification: ANSI/UL Listed, Pkg Qty: 1, Package Type: Box No. HOM220C: Amperage: 20, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-In, Wire Size: 14-8 AWG Al/(2) 14-10 AWG Cu, Certification: ANSI/UL Listed, Pkg Qty: 1, Package Type: Clamshell No. HOM230C: Amperage: 30, Number of Poles: 2, Interruption Type: Standard Trip, Voltage: 120/240, Frame Size: 2-Space, Width (In.): 1, Mount Type: Plug-

Sold as Unit of Measure:EACH

Minimum/Multiple Order Quantity:1
